If you're unable to install the RO system under the sink, you can install it in a remote location. This article is a concise checklist of the steps in the owner's manual. If you're going to install it directly under the sink, click here.
Click below to expand instructions.
Installation Checklist
We recommend you create a checklist to ensure you don’t miss any important steps. We've created one for you below but you should also use the Owner's Manual during this process to ensure proper installation:
- The system can be installed directly under the sink, or remotely if you need more space.
- Keep in mind where you'll be installing the faucet. You may use an existing hole in the sink or need to drill a new one.
- Go ahead and gather your tools according to the Owner’s Manual.
- You'll want to gather and inventory the installation parts and accessories that came with the unit.
- Now, you can turn the cold water supply off and open/turn on your sink faucet to release pressure.
- Install the Cold Water Supply Fitting to the water supply line.
- You're ready to place the Reverse Osmosis Filter Assembly into the preferred location. If mounting the unit, make sure to leave enough room to easily change filters.
- Go ahead and install the storage tank but don't connect the tubing yet.
- Now, determine the sink top location for the faucet if you haven't already.
- Install the faucet onto the hole.
- Time to cut the tubes to your desired length and connect appropriately to the unit, supply, and tank.
- Last step here is to route the red tube to a nearby drain, such as a laundry sink or floor drain. Make sure you leave an air gap of at least 1 1/2" between the red hose and the drain. Then follow the instructions in the next section to get the new RO unit ready for use. Pro Tip: When installing the unit in a remote location, the black tube isn't necessary and can be discarded.
Sanitize, Test, and Purge Checklist
Continue to follow the Owner's Manual carefully when performing the next steps.
- Sanitize the system with household bleach as described in Step G of the Owner’s Manual.
- Open the water supply to Pressure test the system for about 2 hours and examine for leaks.
- Purge the new unit. This rinses out any carbon fines or loose material from the filter cartridges.
